Foldable LED Grow Light Bar Module A
Products Specifications
| Specification | Model: EG-FBMGLA-9005-EX | Model: EG-FBMGLA-9005-EX (3-Fold) | Model: EG-FBMGL-12005-EX |
|---|---|---|---|
| Product Name | Foldable LED Grow Light Bar Module A | Foldable LED Grow Light Bar Module A | Foldable LED Grow Light Bar Module A |
| Product Size (Unfolded) | L1200W1100H45 mm | L1200W1100H45 mm | L1200W1100H45 mm |
| Folding Panels | 2 | 3 | 2 |
| Wattage (W) | 900W | 900W | 1200W |
| Number of Light Bars | 6 | 6 | 8 |
| LED Quantity | 47/64 per bar (Configurable) | 47/64 per bar (Configurable) | 47/64 per bar (Configurable) |
| PPFD @ 0.3m (μmol/s/m²) | 1800 ~ 2000 | 1800 ~ 2000 | 2160 ~ 2400 |
| PPE (μmol/J) | 2.4 ~ 2.9 | 2.4 ~ 2.9 | 2.4 ~ 2.9 |
| Power Factor (PF) | > 0.95 | > 0.95 | > 0.95 |
| Flicker Status | Flicker-Free | Flicker-Free | Flicker-Free |
| Input Voltage & Frequency | AC100~277V, 50/60Hz | AC100~277V, 50/60Hz | AC100~277V, 50/60Hz |
| Dimming & Control | 0-10V / PWM via Master Controller & APP | 0-10V / PWM via Master Controller & APP | 0-10V / PWM via Master Controller & APP |
| Beam Angle | 120° | 120° | 120° |
| IP Rating | IP65 (Dustproof and Waterproof) | IP65 (Dustproof and Waterproof) | IP65 (Dustproof and Waterproof) |
| Color Rendering Index (CRI) | >80 (Ra) | >80 (Ra) | >80 (Ra) |
| Operating Temperature | -15°C to +40°C | -15°C to +40°C | -15°C to +40°C |
| Warranty | 5 Years | 5 Years | 5 Years |
Key Features
Revolutionary Foldable & Modular Design
Boasting an innovative foldable and modular structure, this grow light ships flat to greatly cut down ocean and air freight expenses while easing warehouse storage and inventory management. It can be unfolded effortlessly on-site to cover a large planting canopy, ready for direct hanging and immediate use. The thoughtful design drastically saves on installation time and lowers overall labor costs for commercial growers.
Advanced Smart Control Ecosystem
Take full command of your entire lighting system anytime, anywhere right from your smartphone. Paired with a master controller and dedicated APP, it supports 0-10V and PWM dimming functions. You can freely set custom light recipes, simulate natural sunrise and sunset cycles, and configure precise DLI schedules to create an ideal fully automated growing environment.
Customizable Full Spectrum for Diverse Plant Growth
Featuring flexible power options ranging from 20W to 80W with LED quantities from 180 to 400 beads, it provides adjustable full-spectrum lighting to fit a wide range of plant species and all growth stages. Ideal for leafy greens, vegetables and flowering plants, the tunable full spectrum closely replicates natural sunlight to promote steady germination, robust vegetative growth, and healthy flowering and fruiting performance.
