6W 10W T5 T6 PC Aluminum LED Tube Light

This T5/T6 PC aluminum LED tube represents a remarkable achievement in the deep integration of modern lighting engineering and materials technology. The product employs an innovative PC+aluminum alloy hybrid structure design, perfectly combining the superior heat dissipation performance of aluminum with the excellent light transmittance and impact resistance of polycarbonate (PC). This ensures efficient heat dissipation while achieving a more uniform, softer, and more stable light output. This structure not only effectively extends the lifespan of the luminaire but also significantly improves the overall lighting quality.

This tube is fully compatible with standard T5/T6 tube specifications and supports direct AC power connection (AC Direct), eliminating the need for complex external drivers or wiring modifications, greatly simplifying the installation process and significantly reducing construction and maintenance costs. Its meticulously designed G5 lamp holder structure ensures a stable and reliable connection with existing lamp holders, making replacement and upgrade processes more convenient and efficient.

Furthermore, the product incorporates a high-quality constant current driver, achieving stable power supply through advanced circuit design, effectively reducing flicker, improving energy efficiency, and ensuring stable and reliable performance even during long-term operation. Combining high-efficiency LED chips, this lamp tube can significantly reduce energy consumption while providing ample brightness, meeting the high standards of energy conservation and environmental protection required by modern commercial and industrial lighting.

With its efficient heat dissipation, stable drive, convenient installation, and superior optical performance, this T5/T6 PC aluminum LED lamp tube is widely applicable to various scenarios such as commercial spaces, industrial plants, office environments, warehousing and logistics centers, and residential lighting. It not only brings users a higher quality lighting experience but also provides a more forward-looking solution for upgrading and energy-saving retrofitting of lighting systems, setting a new industry benchmark in terms of efficiency, reliability, and ease of use.

• Direct AC Power Input - No ballast or external driver required
• Advanced Hybrid Construction - PC + Aluminum for optimal thermal management
• Dual T5/T6 Compatibility - Universal fit for multiple fixture types
• Superior Efficiency - Up to 130 lm/W for maximum energy savings
• Premium Color Quality - Ra80/Ra90 CRI options for true color representation
• Flexible Operation - Standard and flicker-free versions available
• Specialized G5 Cap - Perfect fit for standard T5/T6 fixtures
• Universal Voltage - AC100-277V for global applications
• Durable Design - Combines strength with lightweight performance

Detailed Specifications

LED Chip: SANAN 2835

Housing Material: Polycarbonate + Aluminum Composite

Luminous Efficacy: 100-130 lm/W

Beam Angle: 120°

Input Voltage: AC100-277V 50/60Hz

Power Factor: >0.90

IP Rating: IP20

CRI Options: Ra>80 / Ra>90

Dimming: Non-dimmable

Flicker Options: Standard / Flicker-Free

Operating Temperature: -15°C to +40°C

Warranty: 3 Years

End Cap: Special G5 Design
